Product Details
＋
Features:
- Requires the TCPA400
- AC / DC Measurement Capabilities: DC – 2 MHz
- 750 A DC
- Automatic Scaling and Units – Oscilloscope On-Screen Readout of Magnitude and Units Reduces Measurement Errors with No More Hand Calculations
- AC / DC Input Coupling
- Low Insertion Impedance Reduces Device Under Test Loading
- Small Mechanical Package – Less Desktop Space, Easier Storage and Handling
- Split-Core Construction Allows Easy Circuit Connection
- Status Indicators Provide Visual Operating Status and Notificatin of Potential Error Conditions
- Lower DC Drift and Noise Allows Improved Low Level Current Measurements
- Certified for U.S., Canada, and Europe
Applications:
- Power supplies (switching and linear)
- Semiconductor devices (SCRs, IGBTs, MOSFETs, CMOS, BJTs)
- Power inverters/converters
- Electronic ballasts
- Industrial/consumer electronics
- Mobile communications (phone, satellite, relay stations)
- Motor drives
- Transportation systems (electronic vehicles, electric trains, locomotives, avionics)
Specifications:
- 2 MHz
- 500 A
The Tektronix TCPA400 amplifier with the TCP404XL current probe measures 500 A DC continuous and 750 A DC continuous, derated with duty cycle.
